UWB module UWB indoor positioning wired time synchronization positioning system is helpful for industrial digital transformation, wired time synchronization positioning system solves the synchronization error of the space chain between the base station and the base station in wireless synchronization. Greatly improve the accuracy and stability of the system.
Digitization has become the hottest industry term right now. It is not only the technical focus of information technology development, but also the new core direction of the transformation and layout of many industrial enterprises. As a participant in promoting industrial digital transformation, we have been committed to providing enterprise customers with valuable positioning data services from two aspects of safety and lean production.
Relying on the core technology advantages and sensitivity to the digital construction of the industry, we will continue to complete the application and practice of innovative products. At present, UWB module UWB indoor positioning wired time synchronization positioning system has been established with domestic and foreign advanced manufacturing enterprises such as Procter & Gamble, Bosch, Bosch Rexroth, Conch Cement, Baowu Group, Unilever, Yutong Bus, FAW-Volkswagen, Dongfeng Nissan, E-ink and so on. a good cooperative relationship. Behind this, inseparable is continuous technological innovation, stable product quality and efficient service quality.
Under the general trend of digital factory construction, the traditional UWB positioning system architecture also faces the following challenges in industrial scenarios with changing environments:
1. The production workshop environment is complex. Due to the limitations of various facility layouts and transformation conditions, it is inconvenient for UWB base stations to adopt a star network during deployment;
2. There are many kinds of equipment in the workshop, some of which are assumed to be mobile, which aggravates the uncontrollable multipath effect. The quality of the traditional UWB wireless synchronization chain is deeply affected, which affects the positioning effect of the system and brings huge risks to the reliability of business data.
In order to solve the above problems, the conventional UWB positioning system is technically expanded, and the self-developed UWB module UWB indoor positioning wired time synchronization positioning system solution is proposed.
UWB module UWB indoor positioning wired time synchronization positioning system what is it?
A periodic clock signal is sent to the base station through the wired clock synchronization controller US-10 to achieve clock synchronization free from environmental interference. The synchronization error of the space link between the base station and the base station in wireless synchronization is solved. In addition, US-10 also provides cascaded power supply and digital transmission channels for base stations.
What are the advantages of the conventional UWB module positioning system?
1. The accuracy can reach 5cm
2. The synchronous clock source greatly improves the stability of the system.
3. The construction is convenient, and the power supply can be cascaded through the base station.
4. System concurrent capacity increased by 30%
5. Support 3GHZ-9GHZ full frequency band.
6. The debugging efficiency is increased by 30%-50%
What can be done in a manufacturing scenario?
UWB module UWB indoor positioning high-precision location data, as an important part of smart factory data flow, is one of the three major indicators of time, space and status in smart factory business flow. With the help of indoor positioning technology, it can help manufacturing enterprises improve the level of lean production and refined management, and achieve precise positioning, seamless tracking, intelligent scheduling and efficient coordination of production factors such as factory personnel, vehicles, materials, and materials.
Taking the top 500 auto parts giants as an example, their needs are to deeply integrate cutting-edge technology and production technology to further achieve business innovation and digital transformation and upgrading. The on-site workshop uses the wired time synchronization positioning system as the underlying position perception system to locate production line personnel and shelf materials with a positioning accuracy of 5cm. According to the positioning results and the station matching, analyze whether there are redundant actions on the trajectory, and optimize the work rhythm. The accurate positioning of the goods enables the inventory and quick search of the goods. With the data provided by the UWB module indoor positioning wired time synchronization positioning system, the company has achieved a 20% reduction in labor costs and a 17% increase in productivity efficiency, bringing tangible benefits to the factory.
